SOPIX® Series Sensors
SOPIX® Series Sensors from ACTEON Group are veterinary dental sensors for intraoral imaging and workflow efficiency.
SOPIX® Series SensorsTechnical Specifications
| System Type | Veterinary dental intraoral sensor series |
|---|---|
| Detector Sizes | Size 1: 25 x 39 mm; Size 2: 31 x 42 mm |
| Pixel Pitch | 20 µm x 20 µm |
| Imaging Technology | CMOS sensor; scintillator; optic fiber; FIBER2PIXEL® technology |
| Image Processing | ACE® Automatic Control Exposure; real-time dose measurement display |
| Connectivity | USB 2.0; TWAIN compatible |
| Software Platform | AIS ≥ 4.5 imaging software |
| Dimensions / Size | Active surface: Size 1: 600 mm² / 20 x 30 mm; Size 2: 884 mm² / 26 x 34 mm; cable length: 3.70 m |
| Compatibility / Retrofit | Windows® and Mac® compatible; compatible with current configurations |
| Imaging Capability | SOPIX®: >12 lp/mm real resolution; SOPIX®2: >18 lp/mm real resolution; 25 lp/mm theoretical resolution |
| Clinical Applications | Veterinary dental radiography; intraoral imaging; caries detection workflow; dental treatment follow-up |
Veterinary Dental Sensor Workflow
SOPIX® Series Sensors support veterinary dental imaging with dose control and streamlined acquisition.
Automatic Dose Control
ACE® technology analyzes exposure in real time and freezes image acquisition once the sensor receives the required dose.
Clear Intraoral Imaging
FIBER2PIXEL® technology uses optical microfibers to support image clarity, contrast, and visualization of dental anatomy.
Adapted for Dental Cases
Two sensor sizes, rounded corners, and positioning guide stripes help support veterinary dental imaging across patient sizes.
