SRS Pocket
The SRS Pocket from AMRAD Medical is a compact X-ray system designed for small spaces, flexible positioning, and efficient workflows.
SRS PocketTechnical Specifications
| System Type | Radiographic X-ray system |
|---|---|
| Mounting / Configuration | Floor-to-wall mounted tube stand with dual rail system |
| Workflow Interface | EZ-Read angulation dial; SSD system status display; electric locks |
| Imaging Capability | Upright chest, extremities, weight-bearing, table exams |
| Dimensions / Size | Fits rooms as small as 9 ft × 9 ft; vertical travel 13.5"–73" |
| Load Capacity | 300 lb patient capacity (mobile table) |
| Imaging Technology | 10:1 grid ratio; 103 line grid |
| Power / Charging | 24VDC powered system; 40–80 kW generator options |
| Compatibility / Retrofit | DR-ready; supports fixed or wireless detector configurations |
| Clinical Applications | General radiography, orthopedic imaging, urgent care imaging |
| Warranty | 5-year parts warranty |
Compact Radiographic System Performance
The SRS Pocket delivers full imaging capability, efficient workflows, and flexible positioning in space-limited environments.
Designed for Small Spaces
Engineered to fit in rooms as small as 9 ft by 9 ft, the system provides full radiographic functionality without requiring a large footprint. This makes it ideal for facilities with limited space.
Flexible Positioning Control
A dual rail system with interlocking tube and wall stand enables smooth positioning. The system can also separate components when needed to improve workflow flexibility in tight spaces.
Efficient Workflow Operation
Features like the EZ-Read angulation dial and system status display provide clear positioning feedback. These tools help reduce setup time and improve exam throughput.
